MIC3+ Series Ignition Controller

Efficiency-enhanced engines, stricter emission regulations,highly compressed mixtures, as well as the use of a great variety of gas types are putting even greater demands on the entire ignition system. Based on its already known MIC3 series, MOTORTECH provides a new enhanced version to customers to also fulfill these greater demands in the future.

With 300 mJ primary energy, the new MIC3+ series provides a reliable combustion on engines up to 12 cylinders even with weakest or fluctuating caloric values of the gas. Next to high variable ignition energy (MOST*) an accurate spark timing and diversified online diagnostics help to improve engine efficiency, spark plug life and availability of the equipment under the strictest emission regulations.

Features
  • Adjustable spark duration and intensity
  • Constant spark intensity via adjusted duration
  • 300 mJ primary energy (500 mJ boost for start phase)
  • Ignition diagnostics (primary and secondary)
  • Fault memory with trend data
  • Integrated CANopen and Modbus RTU interface
  • Easy access per USB port
  • Simple upgrade of existing plants through full compatibility with MIC3 series
MIC3+ with MOST – MOTORTECH Output Stage Technology
Technical Data
  • 10 to 32 VDC supply voltage
  • 6 / 12 ignition outputs
  • 250 VDC primary voltage
  • 300 mJ primary energy (500 mJ boost)
  • 0.1° crankshaft accuracy
  • Triggered by 1 or 2 pickups (magnetic, Hall effect or inductive / configurable)
  • Multiple timing control via: Speed curve/0-20 mA analog input/0-10 V analog input
  • Multiple energy control via MOST (MOTORTECH Output Stage Technology)
  • Programmable firing order
  • 1 multipurpose output (GPO)
  • 1 Auxiliary Synchronization Output (ASO) which can support a detonation control system (e.g. DetCon) or fuel injection pump controllers
  • Ignition release input
  • Go/NoGo output
  • Overspeed shutdown function
  • Access controlled

Downloads

  • MOTORTECH-Bulletin-2023-16-PrdU-MIC3plus-Firmware-New-Release-1.14.0-EN.pdf  (120 KB)
  • Replacement Information
    Replacement Information  (106 KB)
  • Replacement Information
    Replacement Information  (111 KB)
  • MOTORTECH-Bulletin-2022-02-PrdI-MIC-Controllers-Modifications-Q1-2022-EN_01.pdf  (269 KB)
  • MOTORTECH-InstallationLeaflet-Mounting-Kit-MIC3_-01.12.048-DE-EN-2021-04.pdf  (375 KB)
  • Sales Flyer
    Sales Flyer  (296 KB)
  • Operating Manual
    Operating Manual  (7 MB)
  • Application Note Setting Up and Mounting Pickups
    Application Note Setting Up and Mounting Pickups  (842 KB)
  • Application Note Wiring and Communication between Ignition Controller and DetCon2/20
    Application Note Wiring and Communication between Ignition Controller and DetCon2/20  (1 MB)
  • Application Note AIO Activating Connection to MOTORTECH Ignition Controller
    Application Note AIO Activating Connection to MOTORTECH Ignition Controller  (118 KB)
